22
SECTION V
L.E.D. DISPLAY MESSAGES
The light emitting diode (L.E.D.) display informs the operator of cycle status and program verification, and also
displays important diagnostic messages and fault information.
A. L.E.D. DISPLAY OPERATING STATUS
1. Cycles in Progress
While the dryer is operating, the L.E.D. display will read which cycle is in progress. I.E., in a Manual
Drying Cycle (Mode), the L.E.D. display will read “MANUAL DRYING CYCLE”. In the Cool Down
Cycle (Mode), the L.E.D. display will read “COOL DOWN TEMP __ , __ MINUTES REMAIN”.
2.
Cycle Status
While a cycle is in progress, the L.E.D. display will show the progress of the cycle that is being processed.
a. Automatic Drying Cycle
While a cycle is in progress, the cycle status will display ELAPSED TIME __ MIN. During the Drying
Cycle, the Phase 7 non-coin microprocessor controller (computer) monitors the moisture in the load.
b. Timed (Manual) Drying Cycle
While a cycle is in progress, the cycle status will display __ MINUTES REMAIN.
3. Alternate Display Programs
a. The basket’s (tumbler’s) RPM can be displayed by pressing and holding the “DOWN ARROW” key
while a cycle is in progress. If a cycle is not in progress, the board voltage is displayed.
b. The basket (tumbler) temperature can be displayed by pressing and holding the “UP ARROW”
key
at any time.
