Press the up arrow key to increment

the time, the down arrow key to

decrement the time or enter the time

directly. The stop time is adjustable

from 5 to 10 seconds.

1: ENTER STOP TIME 5

TO 10 SECONDS

From

Press ENTER to access

Press ENTER to store

new changes
