5
SYMBOLOGY
Volts
Direct Current
Risk of Electric Shock
Cat. No. ................................................ MXF PTR2
Battery Type ........................................ MX FUEL™
Charger Type....................................... MX FUEL™
Read Operator's Manual
Always wear eye protection
Keep hands and clothing away from
moving parts
Do not wear gloves
Two-person lift
SPECIFICATIONS
RPM ..............................................................39 / 59
Threading Capacity ......... 3 mm - 50 mm (1/8" - 2")
Pipe Capacity Speed 1 ................. 50 mm (2") max
Pipe Capacity Speed 2 ................. 50 mm (2") max
Compatible Dies .........
Oil Capacity ........................................ 3.7 L (1 Gal)
Recommended Ambient
Lifting Weight ................................ 115 kg (254 lbs)
* Lifting weight includes the weight of the tool, heaviest
Operating Temperature ...................
expected accessories, and oil. Always add in the weight
of the battery pack if installed during lift.
WARNING
pipe threader.
the cart latch.
2. Remove battery pack.
3. To set up cart, gently put the cart down and open
Do not use this machine if the foot switch is broken
or missing. The foot switch provides safe control
of the machine, such as emergency shutoff in
case of entanglement.
Fuel Gauge
Setting Up/Collapsing Cart
1. Make sure area is dry, stable and level to support
4.
5.
Pull up on the accessory carriage handles while
placing one foot on the cross bar of the cart until
the locking pin is in place as shown above.
Empty debris tray prior to collapsing/transport-
ing cart.
6. Before collapsing cart, remove the battery pack.
7. Make sure the cutting wheel, die head, and reamer
are in place on the assembly carriage.
WARNING
Do not charge non-rechargeable
batteries.
WARNING
T
injury
o reduce
, and product damage
the risk of fire, personal
due to
a short circuit, never immerse your tool, battery
pack or charger in fluid or allow a fluid to flow inside
them. Corrosive or conductive fluids, such as
seawater, certain industrial chemicals, and bleach
or bleach-containing products, etc., can cause a
short circuit.
ADDITIONAL BATTERY SAFETY RULES
ASSEMBLY
WARNING
WARNING
Always remove battery pack before
changing or removing accessories.
Inserting/ Removing the Battery
Regulatory Compliance Mark (RCM).
This product meets applicable
regulatory requirements.
Do not dispose of electric tools
together with household waste
material. Electric tools and electronic
equipment that have reached the end
of their life must be collected
separately and returned to an
environmentally compatible recycling
facility.
-17
°
C to 51
°
C
(0
°
F to 125
°
F)
Recharge only with the charger
specified for the battery. For
Only use accessories specifically
recommended for this machine.
Fingers can be pinched between the legs of the
cart. To reduce the risk of injury while setting
up/ collapsing, keep fingers out of areas where
the legs are secure in place.
When the machine is armed, the Fuel Gauge
displays the battery pack's remaining run time. The
fuel gauge mirrors the fuel gauge on the battery
pack. When less than 10% of charge is left, 1 light
on the fuel gauge will flash. When the battery
reaches 0% charge, the fuel gauge will flash 8
times. Charge the battery pack.
specific charging instructions, read the
operator’s manual supplied with your charger
and battery.
To insert the battery, slide the pack into the body of
the machine. Make sure it latches securely into
place.
To remove the battery, push the battery latch lock to
the side and squeeze the battery latch lever. Pull
the battery pack away from the machine.
Others may be hazardous.
3 mm - 9.5 mm (1/8" - 3/8")
13 mm - 19 mm (1/2" - 3/4")
25 mm - 50 mm (1" - 2")
