6.5.13 Fan Motor
1
2
3
4
5
6
7
8
4. Remove the screws with a ratchet or stubby screwdriver, dis-
connect the connector and remove the adsorption fan assy.
5. Reverse the disassembly procedure for reassembly.
Adsorption Fan Assy
R.1.0
Maintenance Manual > Disassembly and Reassembly > Electrical Parts > Fan Motor
