15
Syncmode
Selection for
synchronous mode
AUTO/NORM/SINGL/
NONE/SCAN
Automatic /standard /
single pass /slow scan/
immediate scan
Trigmode
Selection for trigger mode
Rising/falling edge
Source
Selection for
trigger channel
CHA/CHB
Threshol
Horizontal Triggering
Position Level
Position:5-198
Enable
Display/Hide Horizontal
Triggering Position Level
ON/OFF
Auto Fit
Automatic adjustment
ON/OFF
T1.Post
Time measurement
cursorT1
Position: 5-248
T2.Post
Time measurement
cursor T2
Position:5-248
Enable.T
Show/hide Time
measurement cursor
ON/OFF
V1.Post
voltage measurement
cursor V1
Site selection: 5-198
V2.Post
voltage measurement
cursor V2
Site selection:5-198
Enable.V
Show/hide voltage
measurement cursor
CHA/CHB/OFF
Page1
Oscillo
Menu
options
function
Annotation for functions
Options for function
and annotation
Basic Function
Specific Parameter Intro
