Min DS202 - Page 18

16
Post
Move horizontally
to check waveform
Select by storage depth
Depth
Internal storage depth
1k～8k
Enable
Show/hide event trigger
line vernier
ON/OFF
Source
Select measurement
channel
CHA/CHB
Type
Select measurement type
FREQ/DUTY/RMS/
Vavg/Vpp/Vmax/Vmin
Signal frequency/duty ratio,
effective voltage value
/average value/peak-to-peak
value/maximum
value/minimum value
Enable
Display/hide
measurement window
ON/OFF
Source
Select measurement
channel
CHA/CHB
Type
Select measurement type
FREQ/DUTY/RMS/
Vavg/Vpp/Vmax/ Vmin
Signal frequency/duty
ratio,effective voltage
value/average value/peak-to-
peak value/maximum
Enable
Display/hide
measurement window
ON/OFF
Page1
Oscillo
Menu item
options
Annotation for functions
Options for function
and annotation
Page2
Measure
Basic Function
Specific Parameter Intro
Chapter 4
