Min DS202 - Page 19

17
Source
Select measurement
channel
CHA/CHB
Type
Select measurement type
FREQ/ DUTY/ RMS/
Vavg/ Vpp/ Vmax/ Vmin
Signal frequency/duty ratio,effective
voltage value /average value/peak-to-
peak value/maximum
Enable
Display/hide
measurement window
ON/OFF
Source
Select measurement
channel
CHA/CHB
Type
Select measurement type
FREQ/ DUTY/ RMS/
Vavg/ Vpp/ Vmax/ Vmin
Signal frequency/duty ratio,effective
voltage value/average value/peak-to-
peak value/maximum
Enable
Display/hide
measurement window
ON/OFF
Source
Select measurement
channel
CHA/CHB
Type
Select measurement type
FREQ/ DUTY/ RMS/
Vavg/ Vpp/ Vmax/ Vmin
Signal frequency/duty ratio, effective
voltage value/average value/peak-to-
peak value/maximum
Enable
Display/hide
measurement window
ON/OFF
Vbat
Battery voltage
Menu
options
function
Annotation for functions
Options for function
and annotation
Page2
Measure
Basic Function
Specific Parameter Intro
Chapter 4
