23
BeneVision N22/N19/N17/N15/N12
Quick Reference Guide
Or
a. Select the Main Menu
quick key, and select Choose Screen from the
Display column.
b. Select the desired screen.
• Normal Screen: Real time waveforms and numeric parameters on the main
display (Configurable).
• Big Numerics: Up to 6 waveforms and numeric parameters in an
expandable view on the main display (Configurable).
• Minitrends: Split screen with continuously displayed graphic minitrends on
left side beside real time waveforms and numeric parameters on the main
display (Configurable).
• OxyCRG: Split screen with OxyCRG (HR trend, SpO
2
trend, and RR trend/
RR waveform) on the lower portion of the display with real time waveforms
and numeric parameters.
• Remote View (Optional): Split screen with viewing information from
another bed(s) on the lower portion of the display with real time waveforms
and numeric parameters on the host monitoring device.
• ECG Half-Screen: (5, 6, or 12 lead wire set): 7 Leads or 8 leadsof ECG on the
upper portion with real time waveforms and numeric parameters on the
main display.
• ECG Full Screen: (5, 6, or 12 lead wire set): 7 leads or 8 leads of ECG with
numeric parameters on the main display.
• ECG 12-Lead (Optional): 12 leads of ECG with numeric parameters on the
main display.
• PAWP (Optional): Split screen with PAWP measurement screen on the
lower portion of the main display with real time waveforms and numeric
parameters.
• Respiratory Loops(Optional): Split screen with Respiratory loop screen on
the left side with real time waveforms and numeric parameters on the main
display.
• Integrated Devices (Optional): Split screen with viewing information from
external device, such as a ventilator and anesthesia machine, on the left
portion of the display with real time waveform and numeric parameters. on
