Mindray iMEC Series User Manual

11
Record
The thermal recorder records patient information, measurement numerics, up to three waveforms, etc.
Starting and Stopping Recordings
To manually start a recording:
Select the hardkey on the front of either the patient monitor
or the recorder module.
Select the [Record] button from the current menu or window.
Automatic recordings will be triggered in the following conditions:
Timed recordings will start automatically at preset intervals.
If both [Alarm] and [Alm Rec] for a measurement are set on, an
alarm recording will be triggered automatically as alarms occur.




To manually stop a recording:
Select the hardkey again.
Select [Clear All Tasks] in the
[Record Setup] menu.
Recordings stop automatically when:
The runtime is over.
The recorder runs out of paper.
When the recorder has an alarm
condition.






Mindray iMEC Series Specifications

General

Display Size	12.1 inches
Display Type	TFT LCD
ECG	3-lead or 5-lead ECG monitoring
Respiration	Yes
SpO2	SpO2
NIBP	Yes
Temperature	Yes
Battery Type	Rechargeable lithium-ion
Networking	Ethernet
Measurement Parameters	ECG, Respiration, SpO2, NIBP, Temperature
Connectivity	Ethernet
Power Supply	100-240 VAC, 50/60 Hz
