Mindray Z50 User Manual

Patient Data Management 9-13
Including:
 Storage Task: displays the DICOM storage task.
 DICOM Print Task: displays the DICOM print task.
 Media Storage Task:
 DICOM media storage task(including disc and USB devices)
 Backup task (system-relevant format): select the exam to be backed up in iStation
and click .
 Send to external devices (including disc and USB devices): select exam data or
images in iStation or Review screen, click or [Send To].
 Print Task
List of the current printing task. Displays the file name, status (printing or suspended),
printer name, submit time etc.
If all print tasks are finished, the print icon will disappear from the screen, if not, please
check the manager to see if there is any failure task.
In the Task Management dialogue box, patient ID, name, destination, progress, type, status,
content and task created time are displayed.
You can do the following operations:
 Delete
Click [Cancel] to cancel the selected task.
 Retry
Click [Retry] to retry the failed task. When the printer ran out of ink or paper, tasks in print
list will be paused. Click [Retry] to continue the paused print task.
 Select All
Click [Select All] to select all the tasks.

Mindray Z50 Specifications

General

Battery Backup	Yes
Power Supply	100-240V AC, 50/60Hz
Display Size	15 inches
Display Type	LCD
Imaging Modes	Color Doppler
Connectivity	DICOM, USB, Ethernet
Applications	Obstetrics, Gynecology, Cardiac, Vascular, Urology, Musculoskeletal
Storage	500GB HDD
Operating System	Windows-based
