Mindray Z50 User Manual

2-10 System Overview
No.
Name
Description
Function
27
3D/4D
/
Press to enter or exit the 3D/4D status.
28
Cursor
/
Press to show the cursor.
29
/
Trackball
Roll the trackball to change the cursor position.
30
Set
/
Press to confirm an operation, same as the left-
button of a mouse.
31
PW
/
Press to enter PW mode
32
Color
/
Press to enter Color mode
33
M
/
Press to enter M mode
34
B
/
Press to enter B mode
35
Measure
/
Press to enter/ exit Application Measurement
36
Update
/
Measurement status: press to switch between the
fixed and active end of the caliper;
Multi-imaging mode: press to change the
currently active window.
iScape: press to start/stop image acquisition.
37
Caliper
/
Press to enter/ exit General Measurement
38
Gain/ iTouch
/
Rotate: to adjust the gain
Press: to enter/ exit iTouch
39
TGC
/
Move to adjust time gain compensation.
40
Focus
Freq./THI
/
Press: to switch between Focus and Freq./THI;
Rotate: to adjust corresponding parameter
41
Depth
Zoom
/
Press: to switch between Depth and Zoom;
Rotate: to adjust corresponding parameter
42
Save 1
/
Press to save, user-defined key
43
Save 2
/
Press to save, user-defined key
44
Freeze
/
Press to freeze or unfreeze the image.
45
Print
/
Press to print: user-defined key.
46
/
Indicator 1
AC indicator
AC supply: light green;
Battery supply: light off.
47
/
Indicator 2
Battery status indicator
Charging: light in orange
Full: light in green
Discharge (electricity >20%): light in green
Discharge (electricity <20%): blinking in
orange
Discharge (electricity <5%): blinking in
orange rapidly
Non-charge/ discharge: light off

Mindray Z50 Specifications

General

Battery Backup	Yes
Power Supply	100-240V AC, 50/60Hz
Display Size	15 inches
Display Type	LCD
Imaging Modes	Color Doppler
Connectivity	DICOM, USB, Ethernet
Applications	Obstetrics, Gynecology, Cardiac, Vascular, Urology, Musculoskeletal
Storage	500GB HDD
Operating System	Windows-based
