5.2 Tightening torques
The corresponding tightening torques are given in the following table.
Mounting kit Mounting parts Screws Washer Tightening tor-
que
PR 6012/01N,
PR 6012/31N
M8-8.8 * 22 Nm
PR 6012/41N
Upper plate
M12-8.8 ** 85 Nm
PR 6012/01N,
PR 6012/31N
M8-8.8 * 22 Nm
PR 6012/41N
Lower plate
M12-8.8 ** 85 Nm
PR 6012/01S,
PR 6012/31S
M8-A2-70 * 16.5 Nm
PR 6012/41S
Upper plate
M12-A2-70 ** 56.0 Nm
PR 6012/01S,
PR 6012/31S
M8-A2-70 * 16.5 Nm
PR 6012/41S
Lower plate
M12-A2-70 ** 56.0 Nm
*
Recommendation for the washers of
M8 mounting screws:
DIN 7349 (d = 21, h = 4) or DIN 9021 or
ISO 7093-2 (d = 24, h = 2)
**
Recommendation for the washers of
M12 mounting screws:
DIN 7349 (d = 30, h = 6) or DIN 9021 or
ISO 7093-2 (d = 37, h = 3)
5.3 Assembly
5.3.1 Safety instructions
WARNING
The vessel may turn over during mounting.
Securing the vessel against tipping is imperative.
Use an appropriate lifting jack.
WARNING
Warning of hazardous area and/or personal injury
The locking washers of the constrainers may only be used once.
Insert new washers in case they have been damaged or removed. Spare parts, see
Chapter 8.1.
Mini FLEX and Mini FLEXLOCK mounting kits PR 6012/01, ../31, ../41 5 Installation
EN-16 Minebea Intec
