9-9. Function of SQ function data
Item Function No. Setting value Contents
Weighing mode SQF-01 0 Simple comparison mode
●1
Sequential mode
2 4 steps comparator mode 1
3 4 steps comparator mode 2
Control mode SQF-02
●0
Batch mode
1 Discharge mode
2 External input changeover
Comparison signal
operation
SQF-05 0 Anytime
1 In stable condition
●2
Synchronizing with batch finish
3 HOLD at synchronizing with batch finish
Near zero comparison
operation
SQF-06
●0
Gross
1 Net
2 OFF
3 |Gross|
4 |Net|
Full comparative operation SQF-07
●0
Gross
1 Net
2 OFF
3 |Gross|
4 |Net|
Batch Monitoring Timer SQF-10
0000 ~ 9999
●0000
Unit：1s
0000：Batch Monitoring Timer OFF
Start above near zero at
the time of batch start
SQF-15
●0
Invalid
1 Effective
Automatic tare at the time
of batch start
SQF-16
●0
Invalid
1 Effective
Batch start delay timer SQF-17
0000 ~ 9999
●0000
Unit：1s
0000：Batch start delay timer OFF
Automatic tare after batch
start delay timer
SQF-18
●0
Invalid
1 Effective
F-flow compare stop timer SQF-20
0000 ~ 9999
●0000
Unit：0.01s
0000：F-flow compare stop timer OFF
M-flow compare stop timer SQF-21
0000 ~ 9999
●0000
Unit：0.01s
0000：M-flow compare stop timer OFF
D-flow compare stop timer SQF-22
0000 ~ 9999
●0000
Unit：0.01s
0000：D-flow compare stop timer OFF
Flow/Discharge brand
setting target
SQF-24
●0
Brand No. 0
1 Brand No. 1
2 Brand No. 2
3 Brand No. 3
4 Brand No. 4
5 Brand No. 5
6 Brand No. 6
7 Brand No. 7
Automatic free fall
compensation
SQF-25
●0
Invalid
1 Effective
Width for the automatic free
fall compensation
SQF-26
00000 ~ 99999
●00000
Unit：1D
00000：Automatic free fall compensation
OFF
Save of automatic free fall
value
SQF-27
●0
Invalid
1 Effective
●Has been set as default
