(1) Sequence error number
A number is written to input register address 12 when a sequence error occurs.
Number Details Action
1 If forcibly stopped by inputting an
emergency stop during weighing
Check the cause of the emergency stop,
reset the error, and restart.
3 If insufficient even after compensation
flow
Alter the compensation flow time and
maximum number of compensation flow
times, and restart.
4 If there is a contradiction in the
comparison values
Check the settings to eliminate the cause
of the contradiction.
5 If the flow time exceeds the time limit Check for flow gate blockage.
6 If the discharge time exceeds the time
limit
Check for discharge gate blockage.
7 If the gross value is smaller than the final
value in discharge control
Check for flow gate blockage.
8 If the net value is greater than or equal to
the (final value – free fall) at the start
Remove the contents in the container.
10 If measurement begins while START is
[Effective] other than for NEAR ZERO,
and no container is placed on the
measuring section
Check that a container is in place.
(2) Status
Status is written as the bits to input register addresses 51, 55, 59, and 63.
Bit Details
Bit15 STABLE
Bit14 TARE WEIGHT CANCELLATION
SETTING
Bit13 TARE WEIGHT CANCELLATION
Bit12 GROSS WEIGHT
Bit11 NET WEIGHT
Bit10 CENTER OF ZERO
Bit9 HOLD
Bit8 ERROR
Bit7 NEAR ZERO
Bit6 FULL FLOW/S1
Bit5 MEDIUM FLOW/S2
Bit4 DRIBBLE FLOW/S3
Bit3 OVER/S4
Bit2 OK/S0
Bit1 UNDER
Bit0 FULL
