(3) Status error codes
Status error codes are written as numbers to input register addresses 52, 56, 60, and 64.
Number Details
1 If zero setting was performed outside the valid zero setting range
2 If a number not on the list was selected for C function or function setting
4 A/D conversion error
8 If tare weight cancellation was performed outside the tare weight cancellation
operation range
10 Lights when the load display exceeds [(-weighing value) - 9D], exceeds [-110% of
weighing value], or exceeds [-20D]. (Depending on C function CF-03 setting)
11 Lights when the load display exceeds [(+weighing capacity) + 9D] or exceeds
[+110% of weighing capacity]. (Depending on C function CF-03 setting)
12 A/D converter input minus over
13 A/D converter input plus over
20 If the load cell output and numerical input is equal to or under -2.5 mV/V and
exceeds the zero adjustment range on the negative side during calibration
21 If the load cell output and numerical input is equal to or over 2.5 mV/V and exceeds
the zero adjustment range on the positive side during calibration
22 If the load cell output and numerical input is under 0 mV/V and does not reach the
span adjustment range during calibration
23 If the load cell output and numerical input is over 3.1 mV/V and exceeds the span
adjustment range during calibration
31 EEPROM writing error
Holding registers (word reading out/writing reference number 4)
Address Data name
1～9 UNUSED
11～12 FINAL/S1
13～14 FREE FALL/S4
15～16 PRIOR TO FIXED VALUE 1/S3
17～18 PRIOR TO FIXED VALUE 2/S2
19～20 OVER
21～22 UNDER
23～24 NEAR ZERO
25～26 FULL
27～28 PRESET TARE WIGHT
29～30 COMPENSATION FLOW TIME
31～32 WAITING TIME FOR JUDGE AFTER COMPENSATION FLOW
33～34 BRAND NO. 1 AUTOMATIC FREE FALL COMPENSATION
35～265 UNUSED
267～268 BRAND NO. 1 FINAL/S1
269～270 BRAND NO. 1 FREE FALL/S4
271～272 BRAND NO. 1 PRIOR TO FIXED VALUE 1/S3
273～274 BRAND NO. 1 PRIOR TO FIXED VALUE 2/S2
275～276 BRAND NO. 1 OVER
277～278 BRAND NO. 1 UNDER
279～280 BRAND NO. 1 NEAR ZERO
281～282 BRAND NO. 1 FULL
283～284 UNUSED
285～286 BRAND NO. 1 COMPENSATION FLOW TIME
287～288 BRAND NO. 1 WAITING TIME FOR JUDGE AFTER COMPENSATION FLOW
289～290 BRAND NO. 1 AUTOMATIC FREE FALL COMPENSATION
291～522 UNUSED
523～524 BRAND NO. 2 FINAL/S1
525～526 BRAND NO. 2 FREE FALL/S4
527～528 BRAND NO. 2 PRIOR TO FIXED VALUE 1/S3
529～530 BRAND NO. 2 PRIOR TO FIXED VALUE 2/S2
531～532 BRAND NO. 2 OVER
533～534 BRAND NO. 2 UNDER
535～536 BRAND NO. 2 NEAR ZERO
537～538 BRAND NO. 2 FULL
539～540 UNUSED
541～542 BRAND NO. 2 COMPENSATION FLOW TIME
