124
(1) Change to calibration mode by communication
Shift to the calibration mode by writing [9] at the holding register address 56833.
(2) Setting of scale interval
The scale interval is written in holding register address 56835 to 56836.
Scale interval : Selectable from 1, 2, 5, 10, 20 and 50.
Error outside the setting range
When the data outside the setting range is written, the following code is set.
Condition Error code Contents
illegal data 0x03 When the data outside the setting range is written
(3) Set of weighing capacity
The weighing capacity is written in holding register address 56837 to 56838.
Setting range : 1 to 99999
Error outside the setting range
When the data outside the setting range is written, the following code is set.
Condition Error code Contents
illegal data 0x03 When the data outside the setting range is written
(4) Set of mass of weight
Mass of weight is written in holding register address 56839 to 56840.
Setting range : 1 to 99999
However, the data is below the weighing capacity.
Error outside the setting range
When the data outside the setting range is written, the following code is set.
Condition Error code Contents
illegal data 0x03 When the data outside the setting range is written
(5) Confirm the stability of zero (Actual weight)
Stable/Unstable is read out from holding register address 56845.
0 : Unstable 1 : Stable
To Next Page
