(6) Calibration at zero by measurement value
The load cell output value is registered in holding register address 56846 as the zero point.
[1] is written in holding register address 56846.
[1] is automatically rewritten as [0] after writing is normally completed.
Setting range : 1
TE-L error
[20] (TE-L) is written in input register address 52 when the read load cell output value is less than -2.5
mV/V which exceeds the range of zero adjustment on a minus side.
Condition Error code Contents
TE-L 0x03 (Zero point) < (-2.5 mV/V)
TE-H error
[21] (TE-H) is written in input register address 52 when the read load cell output value is more than
2.5 mV/V which exceeds the range of zero adjustment on a plus side.
Condition Error code Contents
TE-H 0x03 (2.5 mV/V) < (Zero point)
Error outside the setting range
When the data outside the setting range is written, the following code is set.
Condition Error code Contents
illegal data 0x03 When data outside [1] is written.
(7) Zero calibration by numeric input
Zero is registered by setting the amount of unit mV/V in holding register address 56841 to 56842.
Setting range : -250000 to 250000 (-2.5 mV/V ~ 2.5 mV/V).
TE-L error
[20] (TE-L) is written in input register address 52 when the read load cell output value is less than -2.5
mV/V which exceeds the range of zero adjustment on a minus side.
Condition Error code Contents
TE-L
－
Zero point mV/V value < -250000
TE-H error
[21] (TE-H) is written in input register address 52 when the read load cell output value is more than
2.5 mV/V which exceeds the range of zero adjustment on a plus side.
Condition Error code Contents
TE-H
－
250000 < Zero point mV/V value
Error outside the setting range
When the data outside the setting range is written, the following code is set.
Condition Error code Contents
illegal data 0x03 When the value outside -250000 to 250000 is written.
