(6) Stability check at point No. 3
Weights are placed for the point to be calibrated on the weighing section and Stable/Unstable is read
out from holding register address 56845.
0 : Unstable 1 : Stable
(7) Compensation by 3 points
After putting the weight of the point which should be compensated on the measuring part, the
weight amount at point No.3 is set and registered in holding register address 56855 to 56856.
Setting range : 1 to Maximum display value
LN-L error
[24] (LN-L) is written in input register address 52 when input load value is lower than zero point.
Condition Error code Contents
LN-L
－
(Value at Point No.3) < (Value at Point No.2)
LN-H error
[25] (LN-H) is written in input register address 52 when input load value is higher than weighing
capacity.
Condition Error code Contents
LN-H
－
(Span point) < (Value at Point No.3)
Error outside the setting range
When the data outside the setting range is written, the following code is set.
Condition Error code Contents
illegal data 0x03 When data outside [1] to [Maximum display value] is
written.
(8) Finish the digital linearization mode
The adjusted data for compensation value of digital linearization that is registered temporary are
stored in holding register address 56848 and returned to the measurement mode.
[1] is written in holding register address 56848.
[1] is automatically rewritten as [0] after writing is normally completed.
Error outside the setting range
When the data outside the setting range is written, the following code is set.
Condition Error code Contents
illegal data 0x03 When data outside [1] is written.
(9) Calibration forced finish.
When [0] is written in holding register address 56833 during the calibration procedure, the calibration
is discontinued without storing the calibration data that is registered temporary, and you can return to
the measurement mode.
