16-3. RS-232C and RS-422/485 interface
16-3-1. Specifications for RS-232C interface (P/N: CSD903-P74)
Specification Contents
Communication method Half duplex
Synchronous method Start-stop synchronous method
Baud rate Selectable from 1 200, 2 400, 4 800, 9 600, 19 200 and 38 400 bps
Data bit length Selectable from 7 bit and 8 bit
Parity bit Selectable from No-parity,Even parity and Odd parity.
Stop bit Selectable from 1 bit and 2 bit
Terminator
Selectable from CR＋LF and CR
Transmission data ASCII code
Cable length Within 15 m.
Input/Output monitor With LED (TXD and RXD)
16-3-2. RS-422/485 interface specifications (P/N: CSD903-P76)
Specification Contents
Communication method Half duplex
Synchronous method Start-stop synchronous method
Baud rate
Selectable from 1 200, 2 400, 4 800, 9 600, 19 200 and 38 400 bps
Data bit length Selectable from 7 bit and 8 bit
Parity bit Selectable from none, Even parity and Odd parity.
Stop bit Selectable from 1 bit and 2 bit
Terminator
Selectable from CR＋LF and CR
Transmission data ASCII code
Cable length Approx. 1 km
Address Select one from 0 to 31
No. of connectable unit 32 units at maximum (RS-422 : 10 units)
Termination resistance Built-in (Yes/No is selectable by the connection of terminal boards.)
Input / Output monitor With LED (TXD and RXD)
16-3-3. Operating mode of RS-232C and RS-422/485
The operation mode of RS-232C is selected by the setting of function F-40.
The operation mode of RS-232C is selectable from [Command mode], [Stream mode] and
[Synchronized with print].
Default is selected as [Command mode].
The operation mode of RS-422/485 is selected by the setting of the function F-49.
The operation mode of RS-422/485 is selectable from [Command mode], and [Stream mode].
Default is selected as [Command mode].
When you select the stream mode, the data keeps being output at constant intervals. Also, control
from the host becomes impossible.
