167
Item Function No. Number Contents
Analog output target
71 70
0 : Display interlock, 1 : Gross value,
2 : Net value
Display value at the analog
output of DC4 mA(DC0 V)
71 71
-999999 ~ 999999
Display value at the analog
output of DC20 mA(DC10 V)
71 72
-999999 ~ 999999
Calibration data of the scale
interval (Reference use)
71 90
0 : 1 scale interval, 1 : 2 scale interval,
2 : 5 scale interval, 3 : 10 scale interval,
4 : 20 scale interval, 5 : 50 scale interval
Calibration data of the weighing
capacity (Reference use)
71 91
000000 ~ 999999
Calibration data of the weight
(Reference use)
71 92
000000 ~ 999999
Calibration data of zero
mV/V (Reference use)
71 93
-3.1000 ~ 3.1000 (Unit : 0.00001mV/V)
Calibration data of span
mV/V (Reference use)
71 94
0.00001 ~ 3.1000 (Unit : 0.00001mV/V)
Stability detection time width at
calibration
71 97
00 ~ 99 (Unit : 0.1 s)
・ The command of writing is changing the upper commands [7*] to [8*].
・ The data setting value [90] to [97] is reading out only, because they are relatively contents of
calibration.
