To the
Voltage output load
resistance is 5 kΩ or more.
Current output load resistance is
510 Ω or less.
Make the load resistance suitable for the
specifications.
Analog output check
Correct connecting?
Connect wires surely by referring to the
“16-1-3.
Confirm the setting concerning the
analog output.
Correctly set.
Set correctly according to the
“16-1. Analog output”
No.
No.
No.
Yes
Yes
Yes
Inform Minebea about the contents of
failure and situation in details.
Inform us about the contents of failure
and situation at site in details
