198
RS-232C
(Sold separately.)
Baud rate : Selectable from 1 200, 2 400, 4 800, 9 600,
19 200 and 38 400 bps.
Data bit length : Selectable from 7 bit and 8 bit
Parity bit : Selectable from None, Even and Odd number.
Stop bit : Selectable from 1 bit and 2 bit
Terminator : Selectable from CR + LF and CR
Communication method : Half duplex
Synchronous method : Start-stop synchronous method
Communication data : ASCII code
RS-422/485
(Sold separately.)
Baud rate : Selectable from 1 200, 2 400, 4 800, 9 600,
19 200 and 38 400 bps.
Data bit length : Selectable from 7 bit and 8 bit
Parity bit : Selectable from None, Even and Odd number.
Stop bit : Selectable from 1 bit and 2 bit
Terminator : Selectable from CR＋LF and CR
Communication method : Half duplex
Synchronous method : Start-stop synchronous method
Address : Selectable one from 0 to 31.
Transmission data : ASCII code
Cable length : Approx. 1 km
Connectable units : 32 units at the maximum (RS-422：10 units)
Terminal resistance : Internal
(Selects the presence by connection of terminal board.)
Input/output monitor with LED
Changeover the RS-422/485: Set by function.
Current output
(Sold separately.)
Output : DC4 mA ~ 20 mA
Load resistance : 510 ohm or less
Resoulution : Approx.1/12 000 or more
Non-linearity : 0.02 %F.S.
Over range : Approx.DC2.4 mA at [－OL] display and
Approx.DC21.6 mA at [OL] display.
Output times : 4 times/s, 20 times/s (Synchronous to display
times).
* An internal circuit and photo-coupler are insulated.
Effect due to temperature
Zero point : ±0.005 % F.S./ ℃
Sensitivity : ±0.01 % F.S./ ℃
Voltage output
(Sold separately.)
Output : DC0 V ~ 10 V
Load resistance : 5 k-ohm or more
Resoulution : Approx.1/12 000 or more
Non-linearity : 0.02 %F.S.
Over range : Approx.DC －1 V at [－OL display and
Approx.DC11 V at [OL] display
Output times : 4 times/s, 20 times/s (Synchronous to display
times)
* An internal circuit and photo-coupler are insulated.
Effect due to temperature
Zero point : ±0.015 % F.S./ ℃
Sensitivity : ±0.015 % F.S./ ℃
