18-4. General specifications
Operating
temperature
range
Temperature
-10 ℃ ~ 50 ℃
※The temperature span of JIS B 7611-2 conformity is -10 ℃ ～
40 ℃
Humidity
85 %RH or less (Non condensing.)
Storage temperature range
-20 ℃ ~ 60 ℃
Power supply Power-supply
voltage
AC100 V ~ AC240 V
(Permissible variable range AC85 V ~ AC264 V)
Power supply
frequency
50/60 Hz
Power
consumption
Approx. 10 VA (without options, at AC100 V)
Approx. 18 VA (with options at AC100 V)
Outline dimensions (W×H×D) 144 mm(W)× 72 mm(H)× (less than)146.7 mm(D)
(excludes protruding parts)
Weight
Approx.1.0 kg (without options)
18-5. Standard specifications at the time of shipment
Bridge excitation DC10 V
Span adjustment 10 000 displays with the input of 0.3 mV/V.
Scale interval 1
18-6. Accessories
Instruction Manual 1 piece
Time lag Fuse(2.5A) 1 piece
I/O connector for external
control
1 piece (connector: FCN-361J024-AU, connector cover:
FCN360C024-B)
Connector for standard
communication
1 piece (plug :XW4B-06B1-H1)
Short bar, between A-F and
C-G
2 pieces
Panel mount gasket 1 piece
Connector for BCD output 1 piece (Attached only when optional BCD output is installed.)
Instruction manual for optional
CC-LINK
1 piece (Attached only when optional CC-LINK interface is installed.)
CC-LINK connector 1 piece (Attached only when optional CC-LINK interface is installed.)
