35
Item Function No. Setting value Contents
Stability detection while the set
mode 2 or set of preset tare
CF-20
●0
Invalid
1 Effective
Unit display in sub- display section
while the set mode 2 or set of preset
tare
CF-21
●0
Invalid
1 Effective
Method of setting gravity
acceleration compensation
CF-25
●0
Set the district number
1 Set the numerical value of gravity
acceleration
District number of using place CF-26
(Possible to set
at CF25 = 0)
01 ~ 16 Unit : District
●10
District number of calibration place CF-27
(Possible to set
at CF25 = 0)
01 ~ 16 Unit : District
●10
Gravity acceleration value setting of
using place
CF-28
(Possible to set
at CF25 = 1)
9.000 ~ 9.999
●9.797
Unit : m/s2
Gravity acceleration value setting of
calibration place
CF-29
(Possible to set
at CF25 = 1)
9.000 ~ 9.999
●9.797
Unit : m/s2
Range switch operation CF-40
●0
Range change OFF
1 Changeable two ranges
2 Changeable three ranges
Set of scale interval of the second
range
CF-41 0 1 scale interval
1 2 scale interval
2 5 scale interval
●3
10 scale interval
4 20 scale interval
5 50 scale interval
Boundary value setting in the
second range
CF-42 000000 ~ 999999
●003000
Set of scale interval of the third
range
CF-43 0 1 scale interval
1 2 scale interval
2 5 scale interval
●3
10 scale interval
4 20 scale interval
5 50 scale interval
Boundary value setting in the third
range
CF-44 000000 ~ 999999
●006000
Analog output target CF-70
●0
Display interlock
1 Gross value
2 Net value
Display value at the analog output
of DC4 mA(DC0 V)
CF-71 -999999 ~ 999999
●000000
Unit : 1D
Display value at the analog output
of DC20 mA(DC10 V)
CF-72 -999999 ~ 999999
●010000
Unit : 1D
Calibration data of the maximum
capacity (Reference use)
CF-90
●1
Calibration data of weighing
capacity (Reference use)
CF-91
●10000
●Has been set as default
