Minebea CSD-903-EX - 5-2. FUNCTION OF C FUNCTION DATA

34
5-2. Function of C function data
Item Function No. Setting value Contents
Display position of
decimal point.
CF-01
●0
No decimal point
1 1234.5
2 123.45
3 12.345
4 1.2345
A/D sampling rate CF-02 0 20 times/s
●1
200 times/s
Condition of over display CF-03
0
Bigger than |Weighing capacity ＋9D|
1
Exceeding to the weighing capacity ±110%
●2
Smaller than －20D and larger than weighing
capacity ＋9D
Unit CF-05
●0
No unit
1 g
2 kg
3 t
4 lb
5 N
6 kN
Excitation CF-07
●0
DC10 V
1 DC5 V
2 DC2.5 V
Net weight sign inversion CF-08
●0
Net weight sign not inverted
1 Net weight sign inverted
Operating condition of
zero set
CF-10 0 Operation when it is steady
●1
Operation by unconditional
Effective range of zero
set
CF-11 00 ~ 30
Unit : ±1 % of the weighing capacity
●02
Target of zero tracking CF-12 0 Gross value and net value ( for load display )
●1
Gross value ( only at gross value display )
Data width of zero
tracking
CF-13 00 ~ 99
Unit : 0.1 D
00 : Zero tracking OFF
●01
Time width of zero
tracking
CF-14 00 ~ 99
Unit : 0.1 s
00 : Zero tracking OFF
●00
Operation of power-on-
zero
CF-15
●0
Invalid
1 Valid
Operating condition of
tare weight cancellation
CF-16
●0
Operation when it is steady and 0 < GROSS
≦ Weighing capacity
1
Operate unconditionally and 0 < GROSS ≦
Weighing capacity
2
Operation when it is steady and 0 < GROSS
≦ |Weighing capacity|
3
Operate unconditionally and 0 < GROSS ≦
|Weighing capacity|
Change of data stored
place
CF-17
●0
RAM
1 EEPROM
Power on clear CF-18
000～111
●000
0：Invalid
1：Valid
10
1
digit：Data of tare weight cancellation
10
2
digit：Data of preset tare weight
cancellation
10
3
digit：Data of zero set and zero tracking
●: Has been set as default
