7-2. Function of the function data
Item Function No. Setting value Contents
Setting of digital filter F-01 001 ~ 256
●016
Unit : Moving average time 1 times
Setting of analog filter F-02 0 2 Hz
●1
4 Hz
2 6 Hz
3 8 Hz
4 10 Hz
Display times F-04
●0
4 times/s
1 20 times/s
Setting of stabilizating filter F-05 001 ~ 256
●092
Unit : Moving average time 1 times
Data width of stabilizing filter F-06 000 ~ 999
●020
Unit : 0.1D
000 : Stabilization filter OFF
Time width of stabilizing filter F-07 00 ~ 99
●05
Unit : 0.1 s
00 : Stabilization filter OFF
Lock the key 1 F-08 0000 ~ 1111
●0000
0 : Invalid
1 : Valid
10
0
: key for ON/OFF
10
1
: key for setting
10
2
: key for accumulation/
10
3
: key for the set of tare weight/
Lock the key 2 F-09 0000 ~ 1111
●0000
0 : Invalid
1 : Valid
10
0
: key for tare weight cancellation/▲
10
1
: key for net or gross weight/▼
10
2
: key for zero set
10
3
: key for F/
Stability detection data width F-10 000 ~ 999
●020
Unit : 0.1D
00 : Stabilization filter OFF
Stability detection time width F-11 00 ~ 99
●10
Unit : 0.1 s
00 : Stabilization filter OFF
Operating condition of the
preset tare weight
cancellation
F-15
●0
Invalid
1 Effective
2 Net weight offset operation
Automatic print operation F-16 00 ~ 11
●00
10
0
digits : manual print operation effective only
in the stable.
0 : effective only in the stable
1 : always effective
10
1
digit : Automatic print operation
0 : turn off the automatic printing
1 : automatic printing in the stable
Hold operation F-17
●0
Synchronizing with Hold
1 Synchronizing with Batch Finish
Target of Hold F-18 0000 ~ 1111
●0001
0 : Invalid
1 : Valid
10
0
digit : Display
10
1
digit : Comparison result
10
2
digit : CC-link interface
10
3
digit : Serial interface
● Has been set as default
