48
Item Function No. Setting value Contents
Selection of sub display
section
F-19 ●0
OFF
1
A Brand (1 digit) / Accumulation times (6 digits) /
Accumulation value (8 digits)
2
B Brand (1 digit) / Accumulation times (6 digits) /
Last accumulated data (6 digits)
3
C Brand (1 digit) / Last accumulated data (6
digits) / Accumulation value (8 digits)
4
D Brand (1 digit) / Last accumulated data (6
digits) / OK (6 digits)
5
E Brand (1 digit) / Accumulation times (6 digits) /
OK (6 digits)
6
F Brand (1 digit) / OK (6 digits) / Accumulation
value (8 digits)
7
G Brand (1 digit) / Near zero (6 digits) / Full (6
digits)
8
(No letter) OK (6 digits) / Over (5 digits) / Under
(5 digits)
9
I Brand (1 digit) / OK (6 digits) / Free fall (6
digits)
10
J
Brand (1 digit) / S1 (6 digits) / S2 (6 digits)
11
K Brand (1 digit) / S1 (6 digits) / S3 (6 digits)
12
L Brand (1 digit) / S1 (6 digits) / S4 (6 digits)
13
M Brand (1 digit) / S2 (6 digits) / S3 (6 digits)
14
N Brand (1 digit) / S2 (6 digits) / S4 (6 digits)
15
O Brand (1 digit) / S3 (6 digits) / S4 (6 digits)
16
P Brand (1 digit) / OK (6 digits)
17
Q Brand (1 digit) / Over (5 digits) / Under (5
digits)
18
R Brand (1 digit) / Accumulation times (6 digits)
19
S Brand (1 digit) / Accumulation value (10
digits)
20
T Brand (1 digit) / Last accumulated data (6
digits)
Brand setting target on
comparator
F-20 ●0
Brand 0
1
Brand 1
2
Brand 2
3
Brand 3
4
Brand 4
5
Brand 5
6
Brand 6
7
Brand 7
Operation target on 4
steps comparator
F-21 0000 ~ 1111
●0000
0 : Display interlock
1 : Gross
2 : Net
10
0
digit：Comparator S1
10
1
digit：Comparator S2
10
2
digit：Comparator S3
10
3
digit：Comparator S4
●Has been set as default
