49
Item Function No. Setting value Contents
Operation on 4 steps
comparator
F-22
0000 ~ 1111
●0000
0 : OFF
1 : More than
2 : Less than
10
0
digit：Comparator S1
10
1
digit：Comparator S2
10
2
digit：Comparator S3
10
3
digit：Comparator S4
Operation of 4 steps
comparator S0
F-23
●0
Always OFF
1 On when both of S1 and S2 output are OFF
2 On when both of S1 and S3 output are OFF
3 On when both of S1 and S4 output are OFF
4 On when both of S2 and S3 output are OFF
5 On when both of S2 and S4 output are OFF
6 On when both of S3 and S4 output are OFF
7
On when (Gross weight)≧(Weighing capacity)
Comparator hysteresis
operating conditions
F-24
●0
On delay
1 Off delay
Width of comparator
hysteresis data
F-25 00 ~ 99
●00
Unit : 1D
00 : Hysteresis OFF
Width of comparator
hysteresis time
F-26 00 ~ 99
●00
Unit : 0.1 s
00 : Hysteresis OFF
BCD output operation
mode
F-30
●0
Stream
1 Synchronizing with print
2 Synchronizing with accumulation
3 Synchronizing with finish
BCD output target F-31
●0
Display interlock
1 Gross value
2 Net value
3 Tare weight value
4 Accumulation total amount
5 Accumulation frequency
BCD output logic F-32 0000 ~ 1111
●0000
0 : Negative logic
1 : Positive logic
100 digit : Data output logic (Load data and
decimal point)
101 digit : Polarity logic
102 digit : Flag logic (ERROR, OVER, Stable,
Gross)
10
3
digit : P.C. (Print command) logic
BCD P.C. (Print
command) width
F-33 0 125 ms
●1
25 ms
2 5 ms
BCD output times F-34
●0
4 times/s
1 20 times/s
2 100 times/s
S-I/F automatic print
operation
F-37
●0
OFF
1 Synchronizing with print signal
2 Synchronizing with accumulation signal
3 Synchronizing with finish signal
● Has been set as default.
