8. Various functions by function data
8-1. Digital filter
The digital filter function is a steady function by the running average processing of data into which
A/D is converted.
The running average frequency is selected by setting function F-01.
Setting range: 001-256 Units: 1 time of moving average frequency.
Default is set to [16 times].
The tendency to the characteristic by the running average is shown in the table below.
Running average frequency Little Much
Running average frequency Little Much
Noise proof
Response speed
Sharpness Stable
Quick Slow
8-2. Analog filter
The analog filter function is the function to reduce the noise of the input signal by filtering.
The frequency is selected by C function F-02.
The frequency can be selected from [2 Hz], [4 Hz], [6 Hz], [8 Hz] and [10 Hz].
Default is set to [4 Hz].
8-3. Display frequency
The display frequency can be selected by the setting of function F-04.
The display frequency can be selected from [4 times/s] or [20 times/s].
Default is set to [4 times/s].
8-4. Stabilization filter
The stabilization filter facility is a function to make the digital filter strong when the change width of
the load display, and when the condition continues longer than the fixed time.
8-4-1. Setting of stabilization filter
The moving average frequency for the stabilization filter can be selected by function F-05.
Setting range: 001-256, Unit: 1 time of moving average frequency
Default is set to [92 times].
8-4-2. Data width of stabilization filter
The data width of stabilization filter can be set by the function F-06.
Setting range : 000 ~ 999, Unit : 0.1D, 000：OFF
Default is set to [020].
8-4-3. Time width of stabilization filter
The time width of stabilization filter can be set by the function F-07.
Setting range : 00 ~ 99, Unit : 0.1 s, 00：OFF
Default is set to [05].
