94 Technical Specifications
Transmission Pulse Induction
Technology Multi Period Sensing (MPS), Dual Voltage Technology (DVT),
and Smart Electronic Timing Alignment (SETA)
Coil 11” Round
Audio Output 6.35mm (¼) headphone/speaker socket.
Headphones supplied.
Liquid Crystal Display (LCD) 64 x 128 pixels, transflective with white backlight.
Length Extended: 1300mm (51.2”)
Collapsed: 1100mm (43.3”)
Weight, including 11” Coil
(Excluding Battery and
Accessories)
2.4kg (5.3lbs)
Operating Temperature Range 0°C to 45°C (32°F to 11F)
Storage Temperature Range 20°C to 65°C (–4°F to 149°F)
Type Lithium-ion
Output Voltage 7.4V, up to 8.4V when fully charged.
Maximum discharge current is 1A.
Capacity 9.2Ah
Input (Charge) 12–24V DC / 23A
Weight 780g (1.72lbs)
Operating Temperature Range 0°C to 45°C (32°F to 11F)
Storage Temperature Range 5°C to 25°C preferred, –5°C to 65°C maximum
(41°F to 77°F preferred, 23°F to 149°F maximum)
Battery Charge
Temperature Range
0°C to 45°C (3F to 11F)
Detector
Battery
