With white turn signal lights: PWY24W
1. Turn the steering wheel.
2. Turn the lid counterclockwise, arrow 1, and
remove.
3. Unscrew the inner lid counterclockwise,
and remove it.
4. Pull bulb holder out of the bulb housing; if
needed, loosen it with small tilting move‐
ments if possible.
5. Pull the bulb out of the fixture.
6. Insert the new bulb and install the cover in
the reverse order.
Tail lights, bulb replacement
Overview
Vehicles with a rear fog lamp
1 Side tail lamps
2 Rear fog lamp
3 License plate lamp
4 Center brake lamp
Vehicle with two rear fog lights
1 Side tail lamps
2 Rear fog lights
3 License plate lamp
4 Center brake lamp
Seite 225
Replacing components
MOBILITY
225
Online Edition for Part no. 01 40 2 915 044 - X/16
