Minicom 0DT60001 User Manual

4
4. KVM Extender USB Units
5. Pre-Installation Instructions
Receiver front panel
Receiver back panel
Keyboard
USB Connector
Power
Connector
Mouse
USB Connector
System
Cable
Control Box
(Optional)
Luminance
Selector
Equalization
Selector
Local
Monitor
Computer
Cable
Local
LED
Lock
LED
Lock
Button
Local
Button
Place cables away from fluorescent lights, air conditioners, and equipment that is likely
to generate electrical noise.
