7
The system works on a first-come, first-served basis – press the keyboard or move the
mouse at either the Transmitter (where relevant) or Receiver position to take control of
the Transmitter position computer.
Transmitter Position: Press the Lock button to keep/gain control of the computer
at the Transmitter position. The Lock LED at the Transmitter position illuminates and
blinks at the Receiver position. The Control LED at the Transmitter position illuminates.
Receiver Position: Press the Lock button to keep control of the Transmitter computer
at the Receiver position. The Lock LED at the Receiver position illuminates and blinks
at the Transmitter position.
Press the Local button to gain control of the Receiver computer position. The Local
LED blinks.
Note: You can only gain control by pressing the Lock button if the Lock LED is currently not
blinking.
Pressing the Lock button again at either position releases control and the Lock LEDs
turn off.
9.1 Keyboard Hotkeys
To toggle between the Transmitter and the Receiver position, press: Caps Lock twice,
release, then press C.
To turn the beeper sound on/off, press: Caps Lock twice, release, then press B.
9.2 Adjusting the Picture
To adjust the picture quality, use the included screwdriver to turn the Luminance and
Equalization Picture adjusters located on the Receiver’s rear panel.
9. Operating the KVM Extender USB System
10. Specifications
System Cable Cat5/6/7 FTP 2x4x24 AWG solid-wire cable
Maximum Distance 500 ft. (150 m)
Mouse Support USB mouse
Operating Systems Supported All major operating systems
Management Push button or external control unit
Screen Resolution Up to 1600 x 1200 @ 75 Hz
Operating Temperature 32° to 104°F (0° to 40°C )
Storage Temperature -40°F to 104°F (-40° to 40°C)
Warranty Period 3-year limited
17-04-194-9336F4.indb 7 5/1/2017 3:05:26 PM
