MiniMax FORMULA T1 - 3-2 Machine start

MACHINE SETTING AND USE
3.4 T1
BF-NGB3
3-23-2
3-23-2
3-2
MACHINE STMACHINE ST
MACHINE STMACHINE ST
MACHINE ST
ARAR
ARAR
AR
TT
TT
T
1) Make sure that:
- the emergency buttons are released (otherwise turn them to the arrow direction)
- the motor housing door is closed
- button A2 of main switch (A fig.3.4a) is pressed
- the handle for spindle locking is on position corresponding to spindle unlocking.
2) PROFILING
make sure that:
- hood-fence unit (fig.3.4) is in the right position and clamped by handles (H-L)
- the speed on the display is proper for the tool (see par.7-4).
then:
- turn change-over switch (B) to star position for starting the motor; then after some seconds turn
the change-over switch to delta position.
- to stop the motor turn change-over switch (B) to 0.
- Press button (M) to start the motor
- Press button (L) to stop the motor
