MiniMax FORMULA T1 - 7-7 Fitting the adjustable hood-fence unit

REGOLAZIONI
7.10 T1
BF-NGB71
7-77-7
7-77-7
7-7
FITTING THE ADJUSTFITTING THE ADJUST
FITTING THE ADJUSTFITTING THE ADJUST
FITTING THE ADJUST
ABLE HOOD-FENCE UNITABLE HOOD-FENCE UNIT
ABLE HOOD-FENCE UNITABLE HOOD-FENCE UNIT
ABLE HOOD-FENCE UNIT
FittingFitting
FittingFitting
Fitting
- Rest the hood-fence unit on the worktable and fasten it by clamping handles (L and H fig.7.9).
- By loosening handles (L and H) move the entire hood-fence unit to the position proper fot the
profiling depth required.
- Then tighten handles.
Vertical pressers (A fig.7.9) ensure the constant pressure on the piece.
The guard for the hands supplied in the accessories bag is to be fitted into the holes on the top side
of fence halves (M and P fig.7.9).
A plate for the right use of the guard is applied on it.
Cover (C) of the spindle and tool hinders the ejection of chips or splinters which are sucked by the
proper hood.
IMPORTANTIMPORTANT
IMPORTANTIMPORTANT
IMPORTANT:after adjusting turn the spindle to check if the tool touches the machine parts or the
guard.
