Minka Ormond - Operation and Maintenance; Operating the Remote Control

FIG. 18
FIG. 19
FIG. 20 FIG. 21 FIG. 22
18
12
: Low speed : Medium speed : High speed
The reverse switch is located under the coupling cover (Figure 20). Slide the switch to left for warm weather
operation. Slide the switch to right for cool weather operation.
21
22
summer or winter
Summer Weather (counter clockwise blade rotation)
Winter Weather (Clockwise blade rotation)
WARNNING：Non-rechargeable batteries are not to be recharged. Batteries are to be inserted with the
correct polarity. Exhausted batteries are to be removed from the product. DO NOT DISPOSE OF BATTERIES
IN FIRE. BATTERIES MAY EXPLODE OR LEAK.
