8
11 12
12
13
Note: After making electrical connections, spliced conductors should be turned upward and pushed carefully up into the
outlet box. The wires should be spread apart with the grounded conductor and the equipment-grounding conductor on
one side of the outlet box and ungrounded conductor on the other side of the outlet box.
DIP SWITCH
13
DOWN LIGHT
11
13
(“ DOWN LIGHT”)
Step 4. Connect the ground wire (green or bare copper) from the outlet box to the ground wire of hanging ball and the
ground wire of hanger bracket. Secure wire connection with the plastic wire nut provided. (Fig.13)
