6
Remember to shut the power off at the circuit breaker or fuse box.
WARNING: HOOK UP IN "SERIES ONLY" DO NOT CONNECT THE HOT AND
NEUTRAL WIRES OF ELECTRIC CIRCUIT TO THE WALL CONTROL - DAMAGE TO
THE SWITCH AND POSSIBLE FIRE COULD OCCUR.
1. (Fig. 8) Carefully tuck the wire connections inside the junction box. Secure the
wall control with the two screws provided.
2. Attach the wall plate over the wall control and secure with the two screws
provided.
INSTALLING THE WALL CONTROL
Fig. 8
SCREWS
SCREWS
WALL PLATE
SWITCH
OUTLET BOX
