minkaAire SPACESAVER - INSTALLING THE MOUNTING PLATE

9
Fig. 11
INSTALLING THE MOUNTING PLATE
Step 1. Remove 1 of 3 screws from the mounting ring and loosen the other 2 screws. (Do not
remove)
Step 2. Place the key holes from the mounting plate over the 2 screws previously loosened from the
mounting ring, turn mounting plate until it locks in place at the narrow section of the key holes.
Secure by tightening the 2 screws previously loosened and the one previously removed. (Fig. 11)
MOUNTING
PLATE
SCREWS
MOUNTING RING
