MiTAC Maestro 830 - Page 18

16
NC
NC
17
NC
NC
18
Ground
Ground
19
NC
NC
20
WLAN_DISABLE-
DAC output
21
Ground
Ground
22
PCIE_RST-
Reset
23
PCIe_WIRELESS_RX-
Receive(negative)
24
3VSB
Power
25
PCIe_WIRELESS_RX+
Receive(positive)
26
Ground
Ground
27
Ground
Ground
28
V_1P5
Power
29
Ground
Ground
30
SMB_CLK_RESUME
SMbus CLOCK
31
PCIe_WIRELESS_TX-
Transmit(negative)
32
SMB_DATA_RESUME
SMbus DATA
33
PCIe_WIRELESS_TX+
Transmit(positive)
34
Ground
Ground
35
Ground
Ground
36
USB_PCH_DN10
DATA(negative)
37
Ground
Ground
38
USB_PCH_DP10
DATA(Positive)
39
3VSB
Power
40
Ground
Ground
41
3VSB
Power
42
NC
NC
43
Ground
Ground
44
3VSB
Power
45
NC
NC
46
NC
NC
47
NC
NC
48
V_1P5
Power
49
NC
NC
50
Ground
Ground
51
NC
NC
52
3VSB
Power
GND1
Ground
Ground
GND2
Ground
Ground
T A B L E 14 M INI PCI E SLOT F OR WLAN SIGNA LS
