Mitchell & Johnson SAP201V - Specifications

Page 22 © Mitchell & Johnson UK 2013 SAP201V IB Ver 1.0 Rev 0.0
9. Specifications
Rated output Power
40 W at 8 ohms, 2 ch driven, 1 kHz, 0.8 % THD (IEC)
50 W at 4 ohms, 2 ch driven, 1 kHz,0.8 % THD (IEC)
Dynamic Power
150W
THD (Total Harmonic Distortion)
0.08 % (1 kHz 1 W)
Damping Factor
60 (Front'1 kHz'8 )
Input Sensitivity and Impedance
250 mV/47 k(LINE) 6.5 mV/47 k(PHONO)
Output Level and Impedance
250 mV/47k(REC OUT)
Phono Overload
60 mV (MM 1 kHz 0.5 %)
Frequency Response
20 Hz-50 kHz/+1 dB-3 dB (LINE)
+14 dB, -14 dB, 100 Hz (BASS)
Tone Control
+14 dB, -14dB, 10 kHz (TREBLE)
+0 dB, -14 dB (BALANCE)
Signal to Noise Ratio
>85dB (LINE, IHF-A) 61 dB (PHONO, IHF-A)
Speaker Impedance
4 ohm 8 ohm 16 ohm
Digital Inputs
OPTICAL 1 (Rear), COAXIAL 1 (Rear)
Analog Inputs
PHONO/CD/NET-PLAYER/AUX/TV (REAR) LINE-IN
(FRONT)
Analog Outputs
REC OUT
Headphones
1 x 1/4" (FRONT)
Power Supply
AC 230V, 50/60 Hz
Power Consumption
Max 250W
Dimensions
(WxHxD) : 430 x 80 x 283 mm
Weight
6.3 kg
NOTE: Specifications and design are subject to possible modifications without notice
