Mitchell MIT6501 - Test Timer Setting

-11-
(D) Measurement time setting (Test Timer) ─ Function 2
1. Switch
⑪
the function rotary switch to turn on power and
no meter which function selected (Main page)
2. Press
⑥
SELECT button to enter the minor function
selection.
3. Press
⑦
(value-add) "up" or
⑧
(value-reduce) "down" to
nd the measurement time setting, LCD display the
following pictures respectively:
4. Press
⑨
(ENTER/SAVE), LCD displays the picture
shown in below:
5. Press
⑦
(value-add) "up" or
⑧
(value-reduce) "down"
to set the test Time (form 1 to 30 minutes).
6. After setting is complete, press
⑨
(ENTER/SAVE) to
conrm & save the data measured.
Note: if Test Timer unit needs not to be adjusted, press
⑩
(ESC) to skip it and return back to the minor function
selection.
7. Press
⑩
(ESC) again to return back to the main page.
