4.11 Memory Management
4.11.1 Storing a reading
There are twenty files (F00-F19) that can be used to store the measurement values inside the
gauge. At most 99 records can be stored to each file. The following procedures outline this
process:
1 Press the key to activate the 【File Name】item on the main measurement screen.
2 Use the key and the key to select the desired file to save the data.
3 After a new measurement reading appears, press the key to save the measurement
value to current file.
If the 【Auto Save】 function is enabled, the measurement value will be automatically saved
to current file after a new measurement operation.
4.11.2 Viewing stored readings
Press the key multiple times until the 【Record No】 area On the measurement screen is
highlighted. Use the key and the key to change the record number. The gauge will
automatically read the stored values according the record number from the memory and display
them on the “Thickness Reading” area of the screen simultaneously. If you want to delete the
displaying record data from the memory, just press the key.
The other way to view the stored record is by menu operations. On the 【Memory Manager】
->【View Mem Data】 menu, press the key to activate the memory viewing screen.
F00 05 5%
F01 00 0%
F02 00 0%
F03 00 0%
F04 00 0%
F05 00 0%
F06 00 0%
↓F07 00 0%
At most eight files,
including the file
name, the record
counts and the ratio
used of the file can be
showed on one
screen.
Use the / key
to scroll up/down.
Press to exit
browsing. Press
to see details of that
file.
F01 00 0%
F02 00 0%
F03 00 0%
F04 00 0%
F05 00 0%
F06 00 0%
↓F07 00 0%
Press or to
move the cursor to
the line which you
want to see details.
Press to see
details of that file.
To Next Page
