2.3 Measurement Screen
Battery Information: Display the information of the rest capacity of the battery.
Coupling Status: Indicate the coupling status. While the gauge is taking a measurement, the
coupling status should be on. If it is not on, the gauge is having difficulty achieving a stable
measurement, and the thickness value displayed will most likely be erroneous.
Operating Hint: Show hints of current operation
FIL: File selection；
MEM：Memory data viewing；
PRB： Transducer set；
VEL： Change velocity;
CAL：Velocity calibration；
DPC：Dual Point Calibration state；
ZER：Probe zero state
SCA: Indicate that current thickness measurement mode is scan mode, and not single point mode.
File Name: show current file name.
Record No./Count: Indicate current record number while this item is highlighted, or total record
