Mitel ST100DA - Power Led; Status LED; Network Leds

LEDs
Network LEDs
Each LAN connector provides two LEDs (Link/Act and 10/100/1000) that indicates the activity and
communication speed of the connected network.
LED Color/State Description
Link/Act
Off There is no link present.
Green-Steady There is a link present, but no data packets are being transmitted or received.
Green-Flashing There is a link present, and data packets are either being transmitted or
received.
10/100/1000
Off A 10 Mbps link is present.
Green
Yellow
A 100 Mbps link is present.
A 1000 Mbps link is present.
Power LED
The blue power LED indicates the operating status of the switch.
Light Description
Steady The switch is powered on, and the internal software is running.
Flashing Continuousashingoratwo-ashpatternindicatesafailedinternalself-test(i.e.hardware
failure).Referto“ConguringSwitches”intheMitel Connect System Administration Guide for
detailsonotherashpatterns.
Off Theswitchisnotpoweredon,orthesoftwareisnotrunning.
Status LED
The status LED provides voice switch activity information.
Color Activity Description
Off No ports are assigned.
Green
Steady No ports are handling active calls.
Flashing-Fast At least one port is handling an active call.
Yellow
Steady No ports are handling active calls and at least one port is out of service.
Flashing-Slow The switch is not connected (or has lost connection) to a Mitel server.
Flashing-Fast At least one port is handling an active call and at least one port is out of service.
