Mitox 271MT - Page 28

271MT / 281MT Multi-Tool
28
Original Instructions Version June13
Attaching the Tools / Extension Shafts to the Power Unit
• Rest the power unit/shaft assembly on a at rm surface.
• Ensure that the clamping wing nut (1) is loose
• Carefully t attachment drive shaft assembly (2) into coupler (3), whilst pulling out locator pin (4).
2
3 4
1
