Mitox 271MT - Specifications and Warranty; Technical Specifications

271MT / 281MT Multi-Tool
37
Original Instructions Version June13
Specications
MODEL MITOX 271MT / 281MT
Engine Type Air cooled 2-stroke gasoline engine
Model IE34F-2E
Displacement : ( cm3) 25.4 cc
Max. output 0.7 (kw) in accordance with ISO 8893
Idle speed: rpm (min –1) 2800±150
Max. rpm (min –1) 8700
Fuel tank capacity 0.65L
Fuel Mixture (petrol 40 : Oil 1)
Carburettor Diaphragm type
Spark Plug Torch L8RTC or NGK-R BPMR7A
Transmission Centrifugal clutch, spur gear, cam-crank
Fixation hole diameter: (mm) 25.4
EX-BC (When used with extention shaft as brushcutter)
Dry Weight w/o harness & gasoline 6.4 kg / 6.7kg
Overall size (LxWxH) 1800mmx380mmx250mm
Reduction ratio 22 :17
Cutting head Cutting
width
3 teeth
blade
255mm
Nylon
head
415mm
3 teeth blade thickness 1.4mm
Cutting line diameter 2.4mm
Max. blade rotation
speed:
7500 rpm (min –1)
Rotation direction Counter Clockwise(as seen from above)
