Installing the Nylon Head
• Lay the Brushcutter on its back with the gearbox shaft facing up.
Rotate the gear box shaft until the hole
in the holder A lines up with the slot in
the metal guard.
Insert an Allen key or screwdriver into
the hole in the gearbox cover and into
holder A.
Screw the nylon head anti-clockwise
(turn left) onto the threaded shaft on the
end of the gearbox.
Make sure that the nylon head is
securely locked in position and remove
the Allen key.
A
A
