Specifications
MODEL MITOX 28MT
Engine Type Air cooled 2-stroke gasoline engine
Model IE34F-4A
Displacement : ( cm3) 25.4 cc
Max. output 0.75 (kw) in accordance with ISO 8893
Idle speed: rpm (min
–1)
3100±400
Max. rpm (min –1) 9000
Fuel tank capacity 0.60L
Fuel Mixture (petrol 40 : Oil 1)
Carburettor Diaphragm type
Spark Plug LD L8RTF; CHAMPION RCJ7Y; NGK BPMR7A
Transmission Centrifugal clutch
Fixation hole diameter: (mm) 25.4
Weight (Power Unit Only) 4.63kg
EX-BC (When used as a Brushcutter)
Weight (Power Unit & Attachment) 6.51kg
Weight (Attachment Only) 1.88Kg
Reduction ratio 22 :17
Cutting head Cutting
width
3 tooth
blade
255mm
Nylon
head
415mm
3 tooth blade
thickness
1.4mm
Cutting line diameter 2.4mm
Max. blade rotation
speed:
7500 rpm (min –1)
Rotation direction Counter clockwise (as seen from above)
