28MT Multi-Tool
45
Original Instructions Version June 16
28MTa_160616
Parts List - Body
ID No. Part Number
Description
63 MIGB/T97.1 5X12X1.5 WASHER 5X12X1.5
64 MIGB/T97.1 5X11X2 WASHER 5X11X2
65 MIGB/T97.1 5X12X1.5 WASHER 5X12X1.5
66 MIGB/T845 ST4.8X19 TAPPING SCREW ST4.8X19
67 MI03.06.1.075 FOAM GRIP
68 MITBC430DJ.03.00-1 DRIVE SHAFT
69 MIGB/T6170 M5 NUT M5
70 MITBC431S.05.02-5 SPRING
71 MITBC431S.05.02-8 WIRE A
72 MITBC431S.05.02-9 WIRE B
73 MITBC431S.05.02-10 CONDUIT
74 MITBC431S.05.02-7 THROTTLE CABLE
75 MIGB/T2671.2 M5X14 SCREW M5X14
76 MIGB/T845 ST3.5X9.5 ST SCREW 3.5X9.5
77 MIGB/T845 ST4.2X10 ST SCREW 4.2X10
78 MIGB/T2671.2 M5X14 SCREW M5X14
79 MITBC431S.05.02-4 THROTTLE TRIGGER
80 MIYD38-3.01.11.04-00 ON/OFF SWITCH
81 MITBC431S.05.02-3 LOCK TRIGGER
82 MITBC431S.05.02-6 LOCK SPRING
83 MITBC431S.05.02-00 THROTTLE ASSEMBLY
84 MITBC431D.02.00-2 BLADE COVER
85 MITBC431D.02.00-1 BLADE
86 MIC43.0100.0300 NYLON HEAD ASSY
87 MITBC430D.07.01-00 HARNESS
